Tuf Steel Tri-Clamp Gasket (UNFLANGED)

SKU: 6411000

Size: 1.5"
Price:
$ 8
Purchase Options
$ 8.00 Sale price $ 8.00
$ 7.20 Sale price $ 7.20 $ 8.00 Original price $ 8.00
Monthly Subscription
Subscription detail
Have complete control of your subscriptions

Skip, reschedule, edit, or cancel deliveries anytime, based on your needs.

Description

Brand: Rubber Fab
Color: Grey
Material: Tuf-Steel®
Style: Tri-Clamp®
Temperature Rating: -350°F to 550°F
Type: Type I (Unflanged Gaskets)

SOLD INDIVIDUALLY

Rubber Fab's Tuf-Steel® Sanitary Tri-Clamp® Gaskets are the material of choice when purity, long service life, performance, chemical resistance, and heat resistance are required. Tuf-Steel® Gaskets are 100% leak free when torqued correctly, and will experience minimum creep and cold flow. The Tuf-Steel® material is a unique proprietary blend of non-pigmented PTFE (Teflon®) and 316L Stainless Steel that has been water atomized and passivated. The end result is a Tuf-Steel® Gasket that is non-stick, features no pigmentation, and has ultra-low absorption rates. These Tri-Clamp® Gaskets can maintain seal integrity under large temperature fluctuations with a serviceable temperature range from -350°F to 550°F. We recommend the use of the Torque-Rite® Clamp Nut to get the most out of these gaskets.


Tuf-Steel® is the original metal detectable gasket, the material has always been detectable with metal detectors and magnetic separators. Over 10 years of testing and documented application usage show that Tuf-Steel® is the choice for perfect surface performance, outstanding durability, extended service life and increased up-time for both SIP (steam in place) and WFI (water for injection) applications. Tuf-Steel® Gaskets are ideal for sanitary steam and extreme temperature processes, especially fryer and hot oil applications. Unlike envelope gaskets, the superior strength of the Tuf-Steel® blend will not revert, eliminating creep and cold flow, providing a leak-free seal.

Made in USA


Storing Tuf-Steel® Gaskets:

  • Shelf Life: 20 Years from cure date
  • Store in original packaging in clean and dry warehouse
  • Do not expose to direct sunlight
  • Keep more than 6' away from electric motors
  • Maintain temperature between 65°F and 85°F
Tuf-Steel® Gasket Standards Compliance:
  • FDA CFR 21, 177.1550
  • U.S. Pharmacopeia Class VI Certification
  • USDA Hazard Analysis and Critical Control Points
  • Cytotoxicity Criteria
  • USDA and 3-A Sanitary Standards
  • ASME-BPE Standards for Type I and Type II
  • ADI Free® (Animal Derived Ingredient Free)
  • Current Good Manufacturing Practices (CGMP)
Tuf-Steel® Tri-Clamp® Gasket Features:
  • Color Code: No Dot
  • -350°F to 550°F Temperature Range
  • Proprietary blend of PTFE and 316L (water atomized and passivated)
  • Maintains seal with wide temperature variations
  • Metal Detectable
  • Extended service life
  • Leak-proof performance
  • Extremely durable
  • Great for SIP(steam in place) and WFI (water for injection) applications
  • Non-pigmented
  • Non-stick surface
  • Minimal cold flow and creep
  • 500 CIP/SIP cycles guaranteed
  • Excellent expansion/contraction stability
  • Minimal thermal expansion
  • Excellent Chemical Resistance
  • Compression Controlled Gasket
  • Rouging Eliminated
  • No gasket extrusion into sanitary tube ID
  • No obstruction of flow
Tuf-Steel® Material is also available in:
  • Type II Flanged Tri-Clamp® Gaskets
  • Screen Gaskets
  • Sock Gaskets
  • Orifice Plate Gaskets
  • Gauge Guards
  • O-Rings
  • Mini Steam Trap Orifice Plates
  • ANSI 150# Flange Gasket (1/8" Thick)
  • ANSI 300# Flange Gasket (1/8" Thick)
  • Bevel Seat Gaskets
  • I-Line Gaskets
  • John Perry Gaskets
  • Q-Line Gaskets
  • DIN/ISO
  • X-Ray Detectable
  • 1/8" Thick Sheets
  • 1/8" - 2" Thick Rods
  • Custom Gaskets, Profiles, Cord, Scrapers



1 = Excellent     2 = Good     3 = Acceptable
4 = Marginal     5 = Poor     6 = Do Not Use
Continuous
Stream
Intermittent
Steam
Pure
Water
Ambient
Pure
Water
Hot
Process
Fluids
Ambient
Process
Fluids
Hot
Process
Fluid Variables
0°-100°C
Temperature
Range
Tuf-Steel® 1 1 1 1 1 1 1 -350°-550°F
Tuf-Flex® 1 1 1 1 1 1 1 -20°-300°F
Food-Flex® 1 1 1 1 1 1 1 -30°-250°F
PTFE 1 1 1 1 1 1 3 -100° to 500°F
Silicone
(platinum)
2 2 2 2 2 2 1 -40°-450°F
Silicone
(peroxide)
2 2 2 2 2 2 1 -40°-450°F
FKM 3 2 2 2 2 2 2 -30°-400°F
EPDM
(peroxide)
3 3 3 3 3 3 3 -30°-300°F
Buna 0 0 5 5 5 5 5 -30°-200°F
