Brand:	Unbranded
Color:	Black
Material:	FKM
Style:	Tri-Clamp
Temperature Rating:	-30°F to 400°F
Type:	Type II (Flanged Gaskets)

Sanitary Gaskets

Flanged FKM Tri-Clamp Gaskets are specified by many process equipment manufacturers and are generally suitable for these applications, however service life must be considered and a preventative maintenance program must be in place to mitigate degradation. While acceptable, we do not recommend FKM Gaskets for continuous use in SIP (steam in place) procedures. With that said, FKM Sanitary Gaskets have excellent compatibility with strong acids and maintain a broad range of operating temperatures from -30°F to 400°F.

Storing FKM Flanged Gaskets:

Shelf Life: 10 Years from cure date
Store in original packaging in clean and dry warehouse
Do not expose to direct sunlight
Keep more than 6' away from electric motors
Maintain temperature between 65°F and 85°F

Flanged FKM Gasket Standards Compliance:

FDA CFR 21, 177.2600
U.S. Pharmacopeia Class VI Certification
USDA Hazard Analysis and Critical Control Points
Cytotoxicity Criteria
USDA and 3-A Sanitary Standards
ASME-BPE Standards for Type I and Type II
ADI Free® (Animal Derived Ingredient Free)
Current Good Manufacturing Practices (CGMP)

FKM Flanged Tri-Clamp® Gasket Features:

Color Code: one white dot, one yellow dot • •
-30°F to 400°F Temperature Range
Acceptable for steam applications

FKM Material is also available in:

Type I Unflanged Tri-Clamp® Gaskets
Screen Gaskets
Sock Gaskets
Orifice Plate Gaskets
Gauge Guards
O-Rings
Mini Steam Trap Orifice Plates
ANSI 150# Flange Gasket
ANSI 300# Flange Gasket
Bevel Seat Gaskets
I-Line Gaskets
John Perry Gaskets
Q-Line Gaskets
DIN/ISO
X-Ray Detectable
Sheets
Custom Gaskets, Profiles, Cord, Scrapers

1 = Excellent 2 = Good 3 = Acceptable 4 = Marginal 5 = Poor 6 = Do Not Use
	Continuous Stream	Intermittent Steam	Pure Water Ambient	Pure Water Hot	Process Fluids Ambient	Process Fluids Hot	Process Fluid Variables 0°-100°C	Temperature Range
Tuf-Steel®	1	1	1	1	1	1	1	-350°-550°F
Tuf-Flex®	1	1	1	1	1	1	1	-20°-300°F
Food-Flex®	1	1	1	1	1	1	1	-30°-250°F
PTFE	1	1	1	1	1	1	3	-100° to 500°F
Silicone (platinum)	2	2	2	2	2	2	1	-40°-450°F
Silicone (peroxide)	2	2	2	2	2	2	1	-40°-450°F
FKM	3	2	2	2	2	2	2	-30°-400°F
EPDM (peroxide)	3	3	3	3	3	3	3	-30°-300°F
Buna	0	0	5	5	5	5	5	-30°-200°F
