A magnetic stirrer or magnetic mixer is a laboratory device that employs a rotating magnetic field to cause a stir bar (also called "flea") immersed in a liquid to spin very quickly, thus stirring it. The rotating field may be created either by a rotating magnet or a set of stationary electromagnets, placed beneath the vessel with the liquid. Since glass does not affect a magnetic field appreciably (it is transparent to magnetism), and most chemical reactions take place in glass vessels (i.e. see beaker or laboratory flasks), magnetic stir bars work well in glass vessels. On the other hand, the limited size of the bar means that magnetic stirrers can only be used for relatively small (under 4 liters) experiments. They also have difficulty dealing with viscous liquids or thick suspensions. For larger volumes or more viscous liquids, some sort of mechanical stirring is typically needed.

Magnetic stirrers are often used in chemistry and biology. They are preferred over gear-driven motorized stirrers because they are quieter, more efficient, and have no moving external parts to break or wear out (other than the simple bar magnet itself). Because of its small size, a stirring bar is more easily cleaned and sterilized than other stirring devices. They do not require lubricants which could contaminate the reaction vessel and the product. They can be used inside hermetically closed vessels or systems, without the need for complicated rotary seals. Magnetic stirrers may also include a hot plate or some other means for heating the liquid.

Specifications

Model	HP7
Electrical requirements	110V 60Hz 1-Phase, 450 watts
Temperature range	Ambient to 350°C
Heating plate	Diameter: 7 inches Material: ceramic coated aluminum
Stirring	Min. speed: 110 rpm, max. speed: 2000 rpm Motor power: 40 watts Motor type: brush-less DC motor Max. stirring volume: 1 gallon (3.8 liters, water as media)
Controller	PID control with digital temperature and rotation speed display
External thermocouple	Type: PT100 Cable length: 35 inches Stainless steel probe length: 11 inches Stainless steel probe diameter: 5 mm
Dimensions (WxDxH)	Unit: 7 x 12.5 x 4.5 inches, shipping: 10 x 16 x 9 inches
Weight	Unit: 10 lbs, shipping: 20 lbs
Safety	Thermocouple failure protection Built-in fuse protection
Certification	UL/CSA (optional), CE (standard)
Warranty	One year

Standard package

Part description	Quantity	Part image
Ai HP7 digital heated magnetic stirrer	1 set
External temperature probe	1 pc
Internal temperature plug	1 pc
Boss head	1 pc
Stainless steel support rod (16 inches)	1 pc
PTFE coated stir bar	2 pcs
4 prong stainless steel clamp opens to 3 1/2"	1 pc
User's manual	1 pc
